This article covers Thermalright Phantom Spirit 120 EVO CPUクーラー.

Overview

The Thermalright Phantom Spirit 120 EVO is a dual-tower air cooler from the Taiwanese cooling specialist. It builds on the original Phantom Spirit design by adding a seventh heat pipe and applying a black frosted finish across the entire fin array. Its standout feature is the offset design that shifts the cooling towers away from the memory slots, reducing clearance issues with tall RAM heatsinks. This makes it a practical choice for builders who want high-performance air cooling without sacrificing memory compatibility. The cooler ships with two 120mm TL-K12 PWM fans rated at 2150 RPM and 69 CFM, while keeping noise under 27 dBA. It strikes a solid balance between thermal performance and quiet operation.

Connectivity & Compatibility

The Phantom Spirit 120 EVO supports a wide range of sockets: Intel LGA1700/1150/1151/1155/1156/1200/2011/2066 and AMD AM4/AM5. It works with the latest Intel Core Ultra and AMD Ryzen 7000/9000 series processors out of the box. Dimensions are 125mm wide, 135mm deep, and 157mm tall. Most mid-tower and full-tower ATX cases will accommodate it, but always check your case's maximum CPU cooler height before purchasing. Both fans use 4-pin PWM headers for automatic speed control via the motherboard. The included mounting kit and manual make installation straightforward even for first-time builders.

Product Info

The Phantom Spirit 120 EVO sits in Thermalright's upper-mid-range air cooler lineup. At around ¥8,000, it offers strong competition to entry-level AIO liquid coolers at a lower price point. Warranty is the standard two years. The package includes two TL-K12 fans, Intel and AMD mounting hardware, thermal paste, and an instruction manual. It is widely available on and major Japanese PC component retailers. Market positioning is best described as entry-level high-end air cooling: it delivers near-AIO performance in a simpler, more maintenance-friendly package.

Best Use Cases

Silent PC builders: Users who dislike pump noise from liquid coolers will appreciate the Phantom Spirit's quiet operation. At idle the fans are nearly inaudible, making it ideal for HTPCs or office workstations. Value-conscious gamers: If you are running a Ryzen 7 or Core i7 class CPU and want reliable cooling without spending on an AIO, this cooler delivers excellent price-to-performance. It also avoids the long-term maintenance concerns of liquid cooling. * Users with tall RAM modules: The offset design minimizes interference with large memory heatsinks. However, check your case width, as the 157mm height may still conflict with narrow chassis.

Things to Consider

At 157mm tall, this cooler will not fit in slim or small-form-factor cases. Always verify your case's maximum CPU cooler clearance before buying. Because it is a dual-tower design, it may block the top PCIe slot or interfere with M.2 heatsinks on some motherboards. Review your board's layout ahead of time. Compared to a 240mm AIO, the Phantom Spirit relies more on good case airflow. If your case has restricted intake or exhaust, consider adding or upgrading case fans to get the most out of this cooler. ## FAQ
Q: Does it support the LGA1851 socket? A: Official support for LGA1851 has not been announced, but the mounting hole pattern is identical to LGA1700, so it will likely work. Use at your own discretion until Thermalright confirms compatibility. Q: Is the included thermal paste good enough? A: Yes, the bundled paste has high thermal conductivity and is sufficient for normal use. If you plan heavy overclocking, you may want to upgrade to a premium paste. Q: Can it cool a Ryzen 9 7950X? A: At stock settings, yes. For sustained all-core workloads or overclocking, a larger air cooler or a 280mm+ AIO would be more appropriate.
