Cooler Master NCORE 100 MAX Mini-ITX PCケース

This article covers Cooler Master NCORE 100 MAX Mini-ITX PCケース.

Overview

The Cooler Master NCORE 100 MAX is a purpose-built Mini-ITX PC case that packs an integrated 120mm AIO liquid cooler and an 850W SFX Gold ATX 3.0 power supply into a mere 15.7-liter footprint. Designed for builders who want a high-performance system without the bulk, this case eliminates much of the guesswork from small-form-factor assembly. Despite its compact dimensions, the NCORE 100 MAX accommodates today's largest graphics cards, including the NVIDIA GeForce RTX 5080 and AMD Radeon RX 9070 XT, with support for GPUs up to 356mm in length. The vertical GPU mount and expandable frame (width adjustable from 155mm to 172mm) allow even 4-slot-thick cards to fit comfortably. The included 850W PSU features a 90-degree 12V-2x6 PCIe 5.0 connector capable of delivering up to 600W to the GPU, while custom short cables keep the interior tidy. The case's aluminum and steel construction gives it a premium feel that complements any desk setup.

Compatibility Guide

The NCORE 100 MAX is strictly a Mini-ITX case. It does not support Micro-ATX or ATX motherboards, so verify your board's form factor before purchasing. CPU Cooling: A 120mm AIO liquid cooler with a 38mm-thick radiator and third-generation pump is pre-installed. It is designed to handle CPUs up to AMD Ryzen 7 and Intel Core Ultra 7 class. Air cooling is not supported. Graphics Card: Supports GPUs up to 356mm in length and up to 4 slots thick (with frame extended). Vertical mounting only; a PCIe riser cable is not included. Power Supply: An 850W SFX Gold ATX 3.0 unit is built in, with a 12V-2x6 connector for modern GPUs. No additional PSU purchase is needed. Storage: Space for two 2.5-inch drives (SSD/HDD). No 3.5-inch drive bays. * Cooling Fan: One 140mm fan is pre-installed at the top. Additional fan mounting is not provided.

Product Info

The NCORE 100 MAX is part of Cooler Master's MAX series, representing a premium all-in-one solution for high-end small-form-factor PCs. Released in late 2023, it targets enthusiasts who want a compact yet powerful gaming rig without the complexity of sourcing separate AIO and PSU components. Key specs include a 15.7L volume, dark gray aluminum/steel/plastic construction, and a 120mm AIO with a 38mm radiator. The integrated PSU is an 850W SFX Gold unit with ATX 3.0 compliance. The case carries a 2-year warranty covering the chassis, AIO, and PSU.

Best Use Cases

Compact High-End Gaming Builds: Ideal for users who want to pair an RTX 5080 or RX 9070 XT with a Ryzen 7 or Core Ultra 7 CPU in a small footprint. The pre-installed AIO and PSU simplify part selection and assembly. First-Time Mini-ITX Builders: The integrated components and custom short cables reduce cable management headaches. The expandable frame makes GPU installation straightforward. * Space-Constrained Creators: Suitable for a powerful workstation in a small office or living room. However, limited storage expansion (no 3.5-inch bays) may be a drawback for users needing large HDD arrays.

Things to Consider

Motherboard Limitation: Only Mini-ITX boards are supported. Some boards with oversized VRM heatsinks or M.2 heatsinks may have clearance issues; check dimensions beforehand. Limited Expandability: No room for additional PCIe cards (capture cards, etc.) beyond the GPU. Storage is limited to 2.5-inch drives only. Cooling Customization: The integrated AIO is not easily replaceable. Switching to a different cooler size or an air cooler is not recommended without modification. Price: At around ¥86,000, the case is expensive compared to buying a separate case, AIO, and PSU. However, the convenience and guaranteed compatibility justify the cost for many builders. ## FAQ
Q: Can I install an ATX power supply in this case? A: No. The case comes with a built-in 850W SFX Gold PSU, and there is no room for an ATX unit. The included PSU is sufficient for high-end builds with an RTX 5080 and Ryzen 7. Q: Does the case support horizontal GPU mounting? A: No. The NCORE 100 MAX is designed exclusively for vertical GPU mounting. You will need to purchase a PCIe 4.0 or 5.0 riser cable separately. Q: Can I replace the integrated AIO cooler? A: Technically yes, but the case is optimized for the included 120mm AIO. Replacing it may require modifications. For most users, the stock cooler provides adequate performance for CPUs up to Core Ultra 7 / Ryzen 7.
