This article covers JONSBO ZA-360WR (リバース) PCケースファン.

Overview

The JONSBO ZA-360WR is a unique 3-in-1 case fan unit that combines three 120mm fans into a single frame. Its standout feature is the reverse blade design, which spins opposite to standard fans, making the blade surface visible from the intake side — perfect for showcasing the 4-sided infinity mirror lighting and the aluminum CD-pattern nameplate.
At 28mm thick, it offers a balance of static pressure and airflow, with a PWM-controlled speed range of 700-2400 RPM. Noise levels stay between 21.3 and 37.3 dB(A), making it quiet enough for daily use. The 3-pin ARGB header allows synchronization with motherboard RGB software, creating a cohesive lighting setup.

Compatibility Guide

This unit requires three 120mm fan mounting positions in a row, equivalent to a 360mm radiator space. It fits most ATX mid-tower cases in the front or top panel, but check your case's interior clearance — the 28mm thickness may interfere with tall RAM heatsinks or thick radiators.
Power connections are straightforward: one 4-pin PWM fan header and one 3-pin ARGB header (5V). If your motherboard lacks an ARGB header, you'll need a separate controller. The unit's single-frame design simplifies cable routing, but also means all three fans share the same PWM signal.

Product Info

Released in late 2025, the JONSBO ZA-360WR sits in the mid-to-high segment of the case fan market. It targets gamers and PC enthusiasts who prioritize aesthetics and ease of installation. The total power draw is about 10W, and the maximum noise level of 37.3 dB(A) is acceptable for most builds.
With 68 individually addressable LEDs per fan and the infinity mirror effect, this unit delivers a premium visual experience. The aluminum nameplate adds a touch of elegance that sets it apart from plastic competitors.

Best Use Cases

  • RGB-focused gaming builds: The reverse blade and mirror lighting create a stunning intake-side appearance. Ideal for showpiece PCs with glass side panels.
  • Cable management enthusiasts: Single-frame design reduces cable clutter to one PWM and one ARGB connection. Perfect for clean, minimalist builds.
  • Quiet yet performance-oriented users: At low RPM, the fan is nearly silent; at high RPM, it provides strong airflow for cooling demanding components.
  • Not ideal for: Small form factor cases where 28mm thickness causes clearance issues, or users who need independent fan control (each fan runs at the same speed).

Things to Consider

The 28mm thickness is 3mm more than standard 25mm fans. This can cause interference when mounting a radiator on top of the fan unit, especially in cases with limited clearance. Always measure your available space.
Since the three fans are integrated, a single fan failure means replacing the entire unit. This reduces long-term repairability compared to individual fans.
Reverse blade fans are designed for intake orientation. If you plan to use them as exhaust, the airflow direction is reversed — ensure your case airflow plan accounts for this. Consult the manual for proper mounting orientation.

FAQ

Q: Does this fan blow air in the same direction as a normal fan?
A: No, the reverse blade version spins opposite to standard fans. Standard fans pull air from the frame side and push out the back; reverse fans pull air from the back and push out the frame side. This makes the blade side face inward for better lighting visibility.
Q: Can I control the RGB without a motherboard ARGB header?
A: Yes, but you'll need an external ARGB controller (sold separately). The fan uses a 3-pin 5V ARGB connector, so any compatible controller or hub will work. With a controller, you lose motherboard synchronization but gain standalone control via remote or button.
Q: Can I set each fan to a different speed?
A: No, all three fans share a single PWM signal and run at the same RPM. For independent fan control, you would need three separate standard fans.

Product Disclosure (Amazon)

  • Manufacturer: JONSBO
  • Seller: Amazon US
  • Fulfilled by: Amazon US
  • ASIN: B0DYNSTXLZ
  • Note: This article covers a manufacturer-made product based on Amazon listing details.
