- フォームファクタ
- ATX source (checked 2026-10-19)
- チップセット
- B860 source (checked 2026-10-19)
- Model
- PRIME B860-PLUS-CSM
- CPU (1/2)
- Support Intel® Core™ Ultra Processors (Series 2) , LGA1851; Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**; ** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.; Support Intel® Core™ Ultra Processors (Series 2) , LGA1851*; Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
- CPU (2/2)
- ** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.
- Chipset
- Intel® B860 Chipset
- Memory (1/4)
- 4 x DIMM slots, max. 256GB, DDR5; Supports up to 8666+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*"; Dual channel memory architecture; DIMM Fit; Supports Intel® Extreme Memory Profile (XMP) memory module; ASUS Enhanced Memory Profile III(AEMPIII)
- Memory (2/4)
- * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or Adjustments will be made based on the specifications of mass-produced memory products available on the market.; * *Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
- Memory (3/4)
- 4 x DIMM slots, max. 256GB, DDR5; Support up to 8666+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*; Dual channel memory architecture; DIMM Fit; Supports Intel® Extreme Memory Profile (XMP) memory module; ASUS Enhanced Memory Profile III (AEMP III)
- Memory (4/4)
- * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or Adjustments will be made based on the specifications of mass-produced memory products available on the market.; * Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
- Graphics (1/3)
- 1 x DisplayPort**; 1 x HDMI™ port***; 1 x USB 20Gbps port (USB Type-C®) supports DisplayPort video output****; * Graphics specifications may vary between CPU types.; ** Supports max. 4K@60Hz as specified in DisplayPort 1.4.; *** Supports 4K@60Hz as specified in HDMI 2.1.; **** Supports max. 4K@120Hz as specified in DisplayPort 1.4.; ***** VGA resolution support depends on processors' or graphic cards' resolution.
- Graphics (2/3)
- ****** While installing the operating system, please ensure that your monitor is; connected to the HDMI port on the back I/O panel or to a discrete graphics card.; 1 x DisplayPort**; 1 x HDMI™ port***; * Graphics specifications may vary between CPU types.; ** Supports max. 4K@60Hz as specified in DisplayPort 1.4.; *** Supports 4K@60Hz as specified in HDMI 2.1.
- Graphics (3/3)
- **** VGA resolution support depends on processors' or graphic cards' resolution.; *****While installing the operating system, please ensure that your monitor is connected to the HDMI port on the back I/O panel or to a discrete graphics card.
- Expansion Slots (1/2)
- Intel® Core™ Ultra Processors (Series 2)*; 1 x PCIe 5.0 x16 slot; Intel® B860 Chipset; 1 x PCIe 4.0 x16 slot (supports x4 mode); - To ensure compatibility of the device installed; Intel® Core™ Ultra Processors (Series 2); 1 x PCIe 5.0 x16 slot; Intel® B860 Chipset; 1 x PCIe 4.0 x16 slot (supports x4 mode); 1 x PCIe 4.0 x1 slot
- Expansion Slots (2/2)
- To ensure compatibility of the device installed
- Storage (1/2)
- Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports*; Intel® Core™ Ultra Processors (Series 2)*; M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode); Intel® B860 Chipset; M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode); M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode); 4 x SATA 6Gb/s ports; * Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10.; Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports*
- Storage (2/2)
- Intel® Core™ Ultra Processors(series 2)*; M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode); Intel® B860 Chipset; M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x2 mode); M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode); 4 x SATA 6Gb/s ports; * Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10.
- Ethernet
- 1 x Realtek 2.5Gb Ethernet; ASUS LANGuard
- Wireless & Bluetooth
- M.2 slot only (Key E, CNVi & PCIe)*; * Wi-Fi module is sold separately.; M.2 slot only (Key E, CNVi & PCIe)*; * Wi-Fi module is sold separately.
- USB (1/2)
- Rear USB (Total 6 ports); 1 x USB 20Gbps port (1 x USB Type-C® with DP Alt mode); 2 x USB 10Gbps ports (2 x Type-A); 1 x USB 5Gbps port (1 x Type-A); 2x USB 2.0 ports (2 x Type-A); Front USB (Total 7 ports); 1 x USB 5Gbps connector (1 x USB Type-C®); 1 x USB 5Gbps header supports additional 2 USB 5Gbps ports; 2 x USB 2.0 headers support 4 additional USB 2.0 ports; * USB Type-C® power delivery output: max. 5V/3A; Rear USB (Total 5 ports); 1 x USB 20Gbps port (1 x USB Type-C®)
- USB (2/2)
- 2 x USB 5Gbps ports (2 x Type-A); 2 x USB 2.0 ports (2 x Type-A); Front USB (Total 9 ports); 1 x USB 10Gbps connector(supports USB Type-C®)*; 2 x USB 5Gbps headers support 4 additional USB 5Gbps ports; 2 x USB 2.0 headers support 4 additional USB 2.0 ports; * USB Type-C® power delivery output: max. 5V/3A
- Audio (1/2)
- Realtek 7.1 Surround Sound High Definition Audio CODEC*; - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking; - Supports up to 24-Bit/192 kHz playback; Audio Features; - Audio Shielding; - Premium audio capacitors; - Dedicated audio PCB layers; * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.; Realtek 7.1 Surround Sound High Definition Audio CODEC*
- Audio (2/2)
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking; - Supports up to 24-Bit/192 kHz playback"; Audio Features; - Audio Shielding; - Premium audio capacitors; - Dedicated audio PCB layers; * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
- Back Panel I/O Ports
- 1 x USB 20Gbps port (1 x USB Type-C® with DP Alt mode); 2 x USB 10Gbps ports (2 x Type-A); 1 x USB 5Gbps port (1 x Type-A); 2 x USB 2.0 ports (2 x Type-A); 1 x DisplayPort; 1 x HDMI™ port; 1 x Realtek 2.5Gb Ethernet port; 3 x Audio jacks; 1 x USB 20Gbps port (1 x USB Type-C®); 2 x USB 5Gbps ports (2 x Type-A); 2 x USB 2.0 ports (2 x Type-A); 1 x DisplayPort; 1 x HDMI™ port; 1 x Realtek 2.5Gb Ethernet port; 3 x Audio jacks
- Internal I/O Connectors (1/4)
- Fan and Cooling related; 1 x 4-pin CPU Fan header; 1 x 4-pin CPU OPT Fan header; 1 x 4-pin AIO Pump header; 4 x 4-pin Chassis Fan headers; Power related; 1 x 24-pin Main Power connector; 1 x 8-pin +12V CPU Power connector; Storage related; 3 x M.2 slots (Key M); 4 x SATA 6Gb/s ports; USB; 1 x USB 5Gbps connector (supports USB Type-C®); 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports; 2 x USB 2.0 header support 4 additional USB 2.0 ports; Miscellaneous
- Internal I/O Connectors (2/4)
- 3 x Addressable Gen 2 headers; 1 x Aura RGB header; 1 x Clear CMOS header; 1 x Chassis Intrusion header; 1 x COM Port header; 1 x Front Panel Audio header (F_AUDIO); 1 x S/PDIF Out header; 1 x SPI TPM header (14-1pin); 1 x 10-1 pin Front System Panel header; 1 x Thunderbolt™ (USB4®) header; Fan and Cooling Related; 1 x 4-pin CPU Fan header; 1 x 4-pin AIO Pump header; 4 x 4-pin Chassis Fan headers; Power Related; 1 x 24-pin Main Power connector
- Internal I/O Connectors (3/4)
- 1 x 8-pin +12V CPU Power connector; Storage Related; 3 x M.2 slots (Key M); 4 x SATA 6Gb/s ports; USB; 1 x USB 10Gbps connector (supports USB Type-C® ); 2 x USB 5Gbps headers support 4 additional USB 5Gbps ports; 2 x USB 2.0 headers support 4 additional USB 2.0 ports; Miscellaneous; 2 x Addressable Gen2 headers; 1 x Aura RGB header; 1 x Clear CMOS header; 1 x Chassis Intrusion header; 1 x COM Port header; 1 x Front Panel Audio header (F_AUDIO); 1 x M.2 slot (Key E)
- Internal I/O Connectors (4/4)
- 1 x S/PDIF Out header; 1 x SPI TPM header (14-1 pin); 1 x 10-1 pin Front System Panel header; 1 x Thunderbolt™ (USB4®) header
- Special Features (1/2)
- ASUS 5X PROTECTION III; -DIGI+ VRM (- Digital power design with DrMOS); - LANGuard; - Overvoltage Protection; - SafeSlot; - Stainless-steel back I/O; ASUS Q-Design; - Q-Dashboard; - Q-DIMM; - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]); - Q-Slot; ASUS Thermal Solution; - Flexible M.2 heatsink; - VRM heatsink design; ASUS EZ DIY; - ProCool; - Pre-mounted I/O shield; Aura Sync; - Aura RGB header; - Addressable Gen 2 headers; ASUS 5X PROTECTION III
- Special Features (2/2)
- DIGI+ VRM ( / Digital power design with DrMOS); - ESD Guards; - LANGuard; - Overvoltage protection; - SafeSlot; - Stainless-steel back I/O; ASUS Q-Design; - Q-Dashboard; - Q-DIMM; - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]); - Q-Slot; ASUS Thermal Solution; - M.2 heatsink; - VRM heatsink design; ASUS EZ DIY; - ProCool; Aura Sync; - Aura RGB header; - Addressable Gen2 headers
- Software Features (1/2)
- ASUS Exclusive Software; Armoury Crate; - Aura Creator; - Aura Sync; - Fan Xpert 2+; - Power Saving; ASUS AI Advisor; ASUS DriverHub; ASUS CPU-Z; Adobe Creative Cloud (Free Trial); Norton 360 Deluxe (60 Days Free Trial); WinRAR (40 Days Free Trial); UEFI BIOS; ASUS EZ DIY; - ASUS CrashFree BIOS 3; - ASUS EZ Flash; - ASUS UEFI BIOS EZ Mode; - ASUS MyHotkey; ASUS Exclusive Software; Armoury Crate; - Aura Creator; - Aura Sync; - Fan Xpert 2+; - Power Saving; ASUS AI Advisor
- Software Features (2/2)
- ASUS DriverHub; ASUS CPU-Z; Adobe Creative Cloud (Free Trial); Norton 360 for Deluxe (60 Days Free Trial); WinRAR (40 Days Free Trial); UEFI BIOS; ASUS EZ DIY; - ASUS CrashFree BIOS 3; - ASUS EZ Flash; - ASUS UEFI BIOS EZ Mode; - ASUS MyHotkey
- BIOS
- 256(128+128) Mb Flash ROM, UEFI AMI BIOS; 2 x 128 Mb Flash ROM, UEFI AMI BIOS
- Manageability
- WOL by PME, PXE
- Accessories (1/2)
- Cables; 2 x SATA 6Gb/s cables; Miscellaneous; 1 x M.2 rubber package; 2 x Screw packages for M.2 SSD; 1 x Screw package for M.2 Key E; Documentation; 1 x Quick start guide; Cables; 2 x SATA 6Gb/s cables; Miscellaneous; 1 x M.2 rubber package; 2 x Screw packages for M.2 SSD; 1 x Screw package for M.2 Key E; Documentation; 1 x ACC Express Activation Key Card; 1 x Quick start guide; Cables; 2 x SATA 6Gb/s cables; Miscellaneous; 1 x I/O shield; 1 x M.2 rubber package
- Accessories (2/2)
- 2 x Screw package for M.2 SSD; 1 x Screw package for M.2 Key E; Documentation; 1 x Quick start guide
