This article covers Z270 A Pro.

Overview

The MSI Z270-A PRO is an ATX motherboard built around the Intel Z270 chipset, designed for LGA1151 sockets supporting 6th and 7th generation Intel Core processors (Skylake and Kaby Lake). It offers a solid balance of features for mid-range gaming PCs and productivity workstations, including dual PCIe 3.0 x16 slots for CrossFire multi-GPU setups and support for DDR4 memory up to 64GB. MSI positions this board as a reliable, no-frills platform for enthusiasts and professionals who need stability and decent expansion options without paying a premium. Key technologies like DDR4 Boost and Audio Boost enhance memory performance and audio quality, making it a practical choice for budget-conscious builders.

Compatibility Guide

CPU Socket: LGA1151 — compatible with Intel Core i7/i5/i3, Pentium, and Celeron processors from the 6th (Skylake) and 7th (Kaby Lake) generations. Note: 8th/9th gen Coffee Lake CPUs are not supported despite the same physical socket. Memory: 4x DDR4 DIMM slots, max 64GB, supporting speeds up to DDR4-3800 (OC). XMP profiles are supported for easy overclocking. Form Factor: Standard ATX (305mm x 244mm) — fits most mid-tower and full-tower cases. Expansion: 2x PCIe 3.0 x16 slots (first runs at x16, second at x8), 4x PCIe 3.0 x1 slots. Supports 2-way AMD CrossFire but not NVIDIA SLI. Storage: 6x SATA 6Gb/s ports, 1x M.2 slot (PCIe 3.0 x4 and SATA modes). Intel Optane Memory ready. USB: 2x USB 3.1 Gen2 Type-A (rear), 6x USB 3.1 Gen1, 6x USB 2.0. * Power: Standard 24-pin ATX + 8-pin CPU power. Recommended PSU wattage depends on the CPU and GPU; for a mid-range build, 500W or higher is advised.

Product Info

Released in January 2017, the MSI Z270-A PRO is a mid-range motherboard that targets users who want a stable platform with overclocking support and dual GPU capability at an affordable price. Warranty is typically 3 years (region-dependent). As of 2026, this board is no longer in new retail; it is available through second-hand markets or clearance stock. Key features include DDR4-3800+ memory overclocking, an M.2 SSD slot, USB 3.1 Gen2, and MSI's Audio Boost circuitry. The Click BIOS 5 interface provides intuitive system tuning.

Best Use Cases

Budget Gamers: Pair with a 7th-gen Core i5 or i7 for a capable 1080p gaming rig. CrossFire support allows adding a second GPU later, though modern titles often favor a single powerful card. Creative Workstation (Secondary PC): For video editing or 3D modeling tasks that benefit from 64GB of DDR4 RAM. The stable platform is ideal for a dedicated render or encoding machine. * Used PC Builders: Build a cost-effective system using affordable second-hand 7th-gen CPUs. The Z270 chipset offers good overclocking headroom for the price.

Things to Consider

CPU Generation Limitation: Despite using the LGA1151 socket, this board does NOT support Intel 8th/9th gen CPUs. Always verify your CPU is 6th or 7th gen before purchasing. No SLI Support: Only AMD CrossFire is supported. If you plan to use multiple NVIDIA GPUs, look for a different motherboard. M.2 Bandwidth Sharing: The M.2 slot may share bandwidth with certain SATA ports. Check the manual to avoid conflicts. Lack of Modern Features: No onboard Wi-Fi/Bluetooth, no PCIe 4.0/5.0, no USB-C. For cutting-edge storage or peripherals, a newer platform is recommended. ## FAQ
Q: Can I use an AMD Ryzen CPU with this motherboard? A: No, the MSI Z270-A PRO is exclusively for Intel LGA1151 processors. AMD CPUs are not compatible. Q: What is the maximum memory speed supported? A: Officially up to DDR4-3800 (OC). Actual overclocking results depend on your CPU's memory controller and the memory kit itself. Using XMP profiles is the easiest way to achieve rated speeds. Q: Can I install Windows 11 on this motherboard? A: Technically yes, but 7th-gen Intel CPUs are not officially supported by Windows 11. You would need to add a TPM 2.0 module and accept the unsupported configuration. Windows 10 is the recommended OS for this platform.

Product Disclosure (Amazon)

  • Manufacturer: MSI
  • Seller: CC.apartment
  • Fulfilled by: CC.apartment
  • ASIN: B01MR31OZ8
  • Note: This article covers a manufacturer-made product based on Amazon listing details.
