This article covers MSI MPG Z390 Gaming Edge AC LGA1151 (Intel 第8世代と第9世代) M.2 USB 3.1 Gen 2 DDR4 HDMI DP Wi-Fi SLI CFX ATX Z390 ゲーミングマザーボード.

Overview

The MSI MPG Z390 Gaming Edge AC is an ATX gaming motherboard built on the Intel Z390 chipset, designed for LGA1151 sockets supporting 8th and 9th Gen Intel Core processors (Core i9-9900K, i7-9700K, i5-9600K, etc.). It features four DDR4 DIMM slots with overclocking support up to 4400MHz, dual M.2 slots (one with a thermal heatsink), onboard 802.11ac Wi-Fi and Bluetooth, and Intel I219-V Gigabit LAN. The board targets mid-to-high-end gamers who want a balanced feature set without stepping up to the premium MEG series. With Mystic Light RGB lighting, dual GPU support (2-way NVIDIA SLI and 3-way AMD CrossFire), and a reinforced PCIe slot design, this motherboard is built for immersive gaming and VR experiences. It also includes Turbo USB 3.1 Gen2 ports, Intel Optane Memory support, and a comprehensive audio solution with Realtek ALC1220 codec and Nahimic 3 software. Positioned as a value-oriented Z390 option, the MPG Z390 Gaming Edge AC offers a solid VRM design (8+1 phase), ample connectivity, and a clean aesthetic. It's an excellent choice for builders who already own a 9th Gen Intel CPU or can source one at a good price, especially for a dedicated gaming rig.

Compatibility Guide

CPU Socket: LGA1151, compatible with Intel 8th Gen (Coffee Lake) and 9th Gen (Coffee Lake Refresh) processors. Not compatible with 6th/7th Gen CPUs. Memory: Dual-channel DDR4, 4 slots, max 64GB, speeds up to 4400MHz (OC). Supports XMP profiles. Form Factor: Standard ATX (305mm x 244mm), fits most ATX cases. PCIe: 2x PCIe 3.0 x16 (CPU lanes), 2x PCIe 3.0 x1, 1x PCIe 3.0 x4 (chipset). Supports 2-way SLI and 3-way CrossFire. Storage: 6x SATA 6Gb/s, 2x M.2 slots (M2_1: PCIe 3.0 x4 only; M2_2: PCIe 3.0 x4 or SATA). Intel Optane Memory ready. Power: 24-pin ATX main, 8-pin EPS CPU. Recommended PSU: 650W for i7-9700K + mid-range GPU; 750W+ for i9-9900K + high-end GPU. * Rear I/O: 2x USB 3.1 Gen2 Type-A, 1x USB 3.1 Gen2 Type-C, 2x USB 3.1 Gen1, 2x USB 2.0, HDMI 1.4, DisplayPort 1.2, Wi-Fi antenna, 5 audio jacks, optical S/PDIF out.

Product Info

The MSI MPG Z390 Gaming Edge AC launched in late 2018 with a retail price around $150-$180 USD. It is now only available through remaining stock or the second-hand market. Warranty is typically 3 years (check region). Market positioning is mid-high tier within the Z390 lineup, offering onboard Wi-Fi and a heatsinked M.2 slot that many competing boards at the same price lacked. The chipset TDP is ~6W, but the CPU cooling requirement depends on the installed processor (95W-125W TDP).

Best Use Cases

Budget-conscious gamer building with a 9th Gen CPU: Pair with a Core i5-9600K or i7-9700K for a capable 1080p/1440p gaming rig. Onboard Wi-Fi saves the cost of a separate adapter. Multi-GPU enthusiast: Supports 2-way SLI and 3-way CrossFire, allowing dual GPU setups for legacy multi-GPU workloads or compute tasks. RGB customization lover: Mystic Light with two addressable RGB headers lets you sync lighting with MSI components and third-party strips. Second-hand or surplus parts builder: If you already have a 9th Gen CPU or can find one cheap, this motherboard offers solid features at a low entry point.

Things to Consider

No support for newer CPUs: This board is limited to LGA1151 8th/9th Gen. For a new build, consider a B460, H510, or Z490+ board for 10th/11th Gen or switch to AMD AM4/AM5. Max 64GB RAM: Not suitable for heavy virtualization or memory-intensive workloads that require 128GB+. PCIe 3.0 only: While PCIe 3.0 x16 is still fine for current GPUs, future standards may benefit from PCIe 4.0/5.0. Wi-Fi 5 (802.11ac): If you have a Wi-Fi 6 router, consider adding a separate Wi-Fi 6 adapter for faster wireless speeds. * Availability: New units are scarce; used boards may have outdated BIOS or worn components. Verify BIOS version and physical condition before purchase. ## FAQ
Q: Can I use a Core i9-9900K with this motherboard for overclocking? A: Yes, the 8+1 phase VRM can handle the i9-9900K at stock and mild overclocks. For heavy overclocking, ensure good case airflow to keep VRM temperatures in check. It's not as robust as high-end Z390 boards like the MEG series. Q: How many M.2 SSDs can I install, and are there any SATA port conflicts? A: Two M.2 slots. M2_1 supports PCIe NVMe only. M2_2 supports both PCIe NVMe and SATA. If you use a SATA M.2 drive in M2_2, SATA port 2 becomes disabled. Check the manual for exact mapping. Q: Does this motherboard support Windows 11? A: Officially, MSI lists Windows 10 support, but the board includes a TPM 2.0 header (requires a separate TPM module) or firmware TPM. With a compatible 8th/9th Gen CPU and TPM enabled in BIOS, Windows 11 installation is possible.
