This article covers Thermaltake SWAFAN EX 14 RGB PC冷却ファン 3個パック 500~2000RPM 磁気接続 リバーシブルブレード コントローラー付き CL-F144-PL14SW-A 140mm ブラック.

Overview

The Thermaltake SWAFAN EX 14 RGB 3-Pack redefines cable management for 140mm case fans with its innovative magnetic daisy-chain system. Instead of running individual cables for each fan, you connect up to three fans using a single 12V cable that snaps into place via neodymium magnets. The result is a remarkably clean interior that makes any build look more professional. Each fan spins at 500–2000 RPM with PWM control, delivering up to 81.6 CFM with the standard blades and 79.3 CFM with the reverse blades. Static pressure reaches 3.17 mmH₂O on standard blades, which is sufficient for radiator use or pushing air through restrictive mesh panels. Noise levels are rated at 34.5 dBA (standard) and 38.8 dBA (reverse) — perfectly acceptable for a mid-range fan. The pack includes three reversible blade sets, a controller hub, and three Mag cables. The controller connects via a USB 2.0 internal header and works with TT RGB PLUS 2.0 software for full RGB customization. This is a versatile kit aimed at enthusiasts who value both aesthetics and airflow flexibility.

Compatibility Guide

SWAFAN EX 14 RGB uses the standard 140×140×25 mm form factor, so it fits any case with 140mm fan mounts. It will not fit 120mm-only mounting holes. The controller requires one USB 2.0 internal header (9-pin) on the motherboard, and power is supplied via a single Molex connector. PWM control is handled through a standard 4-pin PWM header. The magnetic connection is strong enough to hold the fans securely during normal use, but if your case has significant obstructions between fan positions, the magnets may not align perfectly. Plan your layout before final assembly.

Product Info

Released in 2023, the SWAFAN EX 14 RGB sits in the mid-to-high tier of Thermaltake's fan lineup. The 3-pack retails for around ¥9,000–¥10,000 in Japan, which is competitive given the included controller and reversible blades. Each fan draws 3.72W at 12V and 3.6W at 5V, so total system power impact is negligible. The fans use hydraulic bearings rated for 40,000 hours at 25°C. Warranty details are available on Thermaltake's official website. The product is widely available through Japan and major PC component retailers.

Best Use Cases

Cable-Conscious Builders If you hate the spaghetti look of multiple fan cables, the magnetic daisy-chain is a game-changer. Three fans require only one visible cable run, making this an excellent choice for glass-panel cases where interior aesthetics matter. Airflow-Flexible Users The included reversible blades let you switch between intake and exhaust without flipping the fan frame. This is especially handy when you want to change airflow direction after the build is complete — just swap the blades, no need to unmount the fan. RGB Synchronization Enthusiasts TT RGB PLUS 2.0 software allows deep customization of the addressable RGB lighting, and it can sync with motherboard RGB ecosystems. If you want a unified lighting theme across your entire system, this fan set integrates smoothly. ## Alternatives
Corsair's LL140 RGB 3-Pack is a direct competitor at a similar price point. It offers 16 individually addressable LEDs per fan, giving it an edge in lighting complexity. However, it lacks magnetic daisy-chain connectivity and reversible blades, so cable management and airflow flexibility are inferior to the SWAFAN EX. Lian Li's UNI FAN SL140 V2 also supports daisy-chaining and is excellent for clean builds. But like the Corsair, it cannot reverse airflow direction without physically flipping the fan. If you prioritize the ability to change airflow direction without remounting, the SWAFAN EX is the better choice.

Things to Consider

First and foremost, these are 140mm fans — they will not fit 120mm mounting holes. Double-check your case specifications before purchasing. The controller also occupies one USB 2.0 internal header, which may conflict with other devices on motherboards with limited headers. The magnetic connection is convenient but not a rigid lock. If you frequently transport your PC, the fans may detach during movement. For a stationary desktop, this is not a concern. Hydraulic bearings have a 40,000-hour lifespan, which is shorter than premium alternatives like Noctua's SSO2 bearings (150,000 hours). This fan set is best suited for standard desktop use, not 24/7 server operation. Finally, TT RGB PLUS 2.0 software is Windows 10/11 only. Linux users will not be able to control the RGB lighting without third-party tools. Keep this in mind if you run a non-Windows OS.

Product Disclosure (Amazon)

  • Manufacturer: Thermaltake
  • Seller: Amazon US
  • Fulfilled by: Amazon US
  • ASIN: B0BWHJ1BH1
  • Note: This article covers a manufacturer-made product based on Amazon listing details.
