This article covers （サーマルテイク）Thermaltake Riing 12 ケースラジエーターファン RGB LED 120mm 調節可能カラー CL-F053-PL12SW-A.

Overview

The Thermaltake Riing 12 RGB is a 120mm high-static-pressure fan designed for both cooling and aesthetics. Its standout feature is the ring of 12 individually addressable RGB LEDs that create vibrant lighting effects. The nine-blade design generates enough static pressure (1.54 mmH2O) to push air through dense radiator fins, making it a solid choice for liquid-cooling builds. The package includes three fans and a digital controller, allowing you to manage up to 80 fans via the proprietary software.

Connectivity & Compatibility

Each fan uses standard 120mm mounting holes and can be installed in most PC cases or radiators. The controller connects to a USB 2.0 9-pin header on the motherboard (internal USB port). One controller supports up to five devices (fans), and the software can handle up to 16 controllers (80 fans total). The system requires Windows 7, 8, 8.1, or 10. Note that RGB control is through Thermaltake's Riing Plus RGB software only; it does not sync with motherboard ARGB headers or third-party ecosystems like ASUS Aura Sync.

Product Info

First released around 2016, the Riing 12 RGB 3-pack (model CL-F053-PL12SW-A) is still widely available on Japan for roughly ¥22,000–¥23,000. The bundle includes three fans, one digital controller, mounting screws, anti-vibration rubber pads, and a coding guide. Warranty is typically 2 years from Thermaltake (check retailer terms). Its market position sits between mid-range and high-end, offering balanced RGB flexibility and cooling performance.

Best Use Cases

RGB enthusiasts building a themed PC: The 12 individually controlled LEDs provide vivid, customizable lighting without needing additional RGB controllers. However, ensure your motherboard has an internal USB 2.0 header. If not, consider a USB 2.0 header splitter or bracket. Not ideal for those who want to sync with motherboard RGB software. Water-cooling users with radiators: With a static pressure of 1.54 mmH2O and airflow of 48.34 CFM, this fan excels at pushing air through radiators. Noise level is rated at 24.7 dBA, which is quiet enough for most environments even at full speed. Users wanting massive fan arrays: The daisy-chain controller system allows up to 80 fans controlled from one software interface. This is excellent for large towers (e.g., Thermaltake View 71) but requires multiple available USB 2.0 headers or a controller hub. Silent-PC builders: The fan operates between 500 and 1500 RPM via PWM, and at low speeds it is nearly inaudible. At max RPM the noise is still moderate, but enthusiasts who demand absolute silence may prefer 140mm fans at lower speeds.

Things to Consider

This fan uses a proprietary 9-pin USB 2.0 connector, not the standard 4-pin PWM fan header. If your motherboard lacks spare internal USB 2.0 headers, you will need an adapter or a USB 2.0 internal hub. Also, the controller does not support PWM speed control through the motherboard; fan speed is set via the software (based on temperature curves). The 730g total weight (3 fans + controller) may strain thin side panels if mounted with screws alone—consider rubber mounts. ## Alternatives
If you need full motherboard RGB sync, consider the Corsair LL120 series or the Lian Li UNI Fan SL-Infinity. Both offer compatible software integration but are more expensive per fan. For pure performance without RGB, the Noctua NF-F12 industrialPPC is a better option. The Thermaltake Riing 12 RGB is a strong middle ground for those who prioritize individual LED control and decent static pressure.

Product Disclosure (Amazon)

  • Manufacturer: Thermaltake
  • Seller: ak.apartment
  • Fulfilled by: ak.apartment
  • ASIN: B0D2C4B3SC
  • Note: This article covers a manufacturer-made product based on Amazon listing details.
