This article covers Lian Li ユニバーサル USB & PWM ファンハブ ホワイト (EG-HUB01W).
Overview
Lian Li's Universal USB & PWM Fan Hub (EG-HUB01W) is a compact expansion hub designed to solve the all-too-common problem of running out of USB headers and fan connectors on your motherboard. It adds four USB 2.0 headers (eight downstream ports) and six PWM fan ports, all powered directly from your PSU via a PCIe power interface. The white finish matches Lian Li's aesthetic lineup, and magnetic mounting makes installation effortless.
Connectivity & Compatibility
Connectivity is straightforward. The hub draws power through a PCIe 6-pin or 8-pin connector, freeing the motherboard from additional fan/USB current load. You connect the hub to your motherboard via a single USB 2.0 internal header cable (9-pin) for data, and to your fans via standard 4-pin PWM cables.
- Fan ports: 6x 4-pin PWM, each rated up to 2A (total 12A max)
- USB headers: 4x USB 2.0 9-pin internal headers, each supporting 2 downstream ports (8 ports total, 2.5A combined)
- Mounting: Built-in magnets for steel cases; also supports direct attachment via PCIe power cable
- Compatibility: Works with any ATX, Micro-ATX, or Mini-ITX case, any PSU with a PCIe power connector, and any motherboard with a standard USB 2.0 internal header
Product Info
The Lian Li EG-HUB01W launched in late 2024 and sits in the mid-to-high accessory tier. It retails for around ¥7,000 (~$50 USD). The package includes the hub, a PCIe power Y-cable, and a USB 2.0 internal cable. Warranty is 1 year from Lian Li. This hub is ideal for builders who need more fan headers and USB ports than their motherboard provides, without resorting to splitters that risk overloading a single header.
Best Use Cases
- High-end PC builders with many fans: If you're running six or more fans (especially power-hungry ones like Lian Li UNI fans), this hub distributes power safely and keeps PWM control intact. Each port handles up to 2A, so even high-speed fans won't hit the limit.
- Enthusiasts adding RGB controllers or other USB devices: Many RGB controllers, AIO pump displays, and fan controllers require internal USB 2.0 headers. The EG-HUB01W provides four such headers, allowing you to connect multiple controllers without conflict.
- Cable-management perfectionists: The magnetic mount lets you attach the hub anywhere inside a steel case, keeping cables tidy and out of sight. For aluminum or non-ferrous cases, you can still secure it using the PCIe cable's natural routing.
However, if your motherboard already has enough fan headers and USB ports (e.g., most high-end boards), this hub is unnecessary. It's also not suitable for DC (non-PWM) fan setups, as it only provides PWM control.
Product Disclosure (Amazon)
- Manufacturer: Lian Li
- Seller: ChaRudonnay STORE
- Fulfilled by: ChaRudonnay STORE
- ASIN: B0DKXPMHBY
- Note: This article covers a manufacturer-made product based on Amazon listing details.
