This article covers GIGABYTE B650M D3HP AX (rev. 1.0) AM5 LGA 1718 AMD B650 M.

Overview

The GIGABYTE B650M D3HP AX (rev. 1.0) is a Micro ATX motherboard supporting AMD Ryzen 7000 series processors on the Socket AM5 platform. Designed for budget-conscious builders, it offers a solid balance of modern features including DDR5 memory, PCIe 4.0 connectivity, built-in Wi-Fi 6E, and 2.5GbE LAN. The 5+2+2 phase digital VRM provides stable power delivery for Ryzen 5 and Ryzen 7 CPUs, making it a reliable choice for entry-level to mid-range PC builds. With a compact footprint, it fits well in smaller cases without sacrificing essential expansion options.

Compatibility Guide

This motherboard supports AMD Socket AM5 processors, including Ryzen 7000 and later 8000 series. It uses DDR5 memory exclusively (no DDR4 support) with two DIMM slots supporting up to 128GB total. The Micro ATX form factor requires a case with M-ATX compatibility. Expansion includes one PCIe 4.0 x16 slot, two M.2 PCIe 4.0 x4 slots, and four SATA 6Gb/s ports. Power requirements are a 24-pin ATX main connector and one 8-pin EPS CPU power connector. A 650W power supply is recommended for typical builds with a mid-range CPU and GPU.

Product Info

The GIGABYTE B650M D3HP AX launched in early 2024 as an entry-level AM5 motherboard. It targets users who want the latest platform features (DDR5, Wi-Fi 6E, PCIe 4.0) at an affordable price point. Typical retail pricing is around ¥20,500. The motherboard comes with a standard 3-year manufacturer warranty and is widely available through major PC component retailers like Japan.

Best Use Cases

Budget AM5 Gaming Build: Pair with a Ryzen 5 7600 and a mid-range GPU for a capable 1080p gaming rig. The integrated Wi-Fi 6E eliminates the need for a separate wireless adapter. Compact Office/Home PC: The M-ATX size allows for a tidy, space-saving build. Adequate for everyday productivity, media consumption, and light creative work. * Entry-Level Workstation: With support for up to 128GB of DDR5 RAM, it can handle memory-intensive tasks like virtual machines or moderate content creation, provided the CPU is chosen accordingly.

Things to Consider

The VRM design (5+2+2 phases) is sufficient for Ryzen 5 and Ryzen 7 but may run hot under sustained full load with high-core-count Ryzen 9 chips. Only two DIMM slots limit future memory expansion; if you anticipate needing more than 32GB immediately, consider a 4-slot board. There is only one PCIe x16 slot, so multi-GPU setups are impossible. The lack of BIOS Flashback means you need a compatible CPU from the start for updates. Also, the board lacks PCIe 5.0 support for M.2 and PCIe slots; PCIe 4.0 is still fast for most users but enthusiasts seeking future-proofing may want a B650E or X670E board. ## Specifications | Item | Specification | |------|---------------| | Chipset | AMD B650 | | Socket | Socket AM5 (LGA 1718) | | Form Factor | Micro ATX | | CPU Support | AMD Ryzen 7000/8000 series | | Memory Slots | 2× DDR5 DIMM (max 128GB) | | Memory Type | DDR5-5200 (OC, EXPO/XMP) | | PCIe x16 Slots | 1× PCIe 4.0 x16 | | M.2 Slots | 2× M.2 PCIe 4.0 x4 | | SATA Ports | 4× SATA 6Gb/s | | Wireless | Wi-Fi 6E (802.11ax) | | Wired LAN | Realtek 2.5GbE LAN | | USB Ports | 1× USB 3.2 Gen2 Type-C (rear), USB 3.2 Gen1/2.0 | | Video Output | HDMI, DisplayPort | | Audio | Realtek 7.1-channel HD Audio | | VRM Phases | 5+2+2 digital VRM | | Power Connectors | 24-pin ATX, 8-pin EPS | | BIOS Flashback | Not supported | | Recommended PSU | 650W |
