This article covers EVGA GeForce RTX 3060 XC ゲーミング.
Overview
The EVGA GeForce RTX 3060 XC Gaming is a mid-range graphics card built on NVIDIA's Ampere architecture. It features the NVIDIA GeForce RTX 3060 GPU with a generous 12GB of GDDR6 memory, making it one of the few cards in its class to offer this much VRAM. The real boost clock reaches 1882 MHz, slightly above the reference specification. This card is ideal for 1080p gaming with ray tracing and DLSS support, delivering smooth frame rates in most modern titles. The dual-fan cooler keeps temperatures under control while remaining relatively quiet, and the full metal backplate adds structural rigidity and a clean aesthetic. Its compact size (about 201mm long) fits comfortably into most mid-tower and many compact cases. Positioned as an entry-to-mid-range option, the RTX 3060 XC strikes a strong balance between price and performance, especially for gamers who want to experience ray tracing without breaking the bank.
Compatibility Guide
Interface: PCI Express 4.0 x16 (backward compatible with PCIe 3.0) Power Requirements: One 8-pin PCIe power connector; recommended PSU wattage of 550W or more (650W for headroom) Form Factor: Dual-slot, 201.5mm x 111.5mm standard dimensions Outputs: 2x DisplayPort 1.4a, 2x HDMI 2.1 (supports up to 4K 120Hz) * VRAM: 12GB GDDR6 (192-bit bus, 15 Gbps effective speed) Most standard ATX and Micro-ATX cases will accommodate this card without issue. For Mini-ITX builds, verify maximum GPU length before purchase.
Product Info
The EVGA GeForce RTX 3060 XC Gaming (model 12G-P5-3657-KR) launched in February 2021. Pricing has fluctuated since launch; currently it retails around ¥89,000 in Japan. EVGA offers a standard 3-year warranty (extendable via product registration). Core specs: GPU GA106-300 with 3584 CUDA cores, 28 RT cores, 112 Tensor cores. Memory configuration: 12GB GDDR6 at 15 Gbps over a 192-bit bus, providing 360 GB/s bandwidth. Total board power (TDP) is 170W. Market position: Entry-to-mid-range gaming GPU, optimized for 1080p high-refresh-rate gaming. It can handle 1440p with adjusted settings or DLSS, but native 4K is best left to higher-tier cards like the RTX 3070 or above.
Best Use Cases
1080p 144fps Gaming: For esports titles and modern AAA games with medium-high settings, the RTX 3060 XC delivers excellent frame rates. DLSS further boosts performance in supported games. Budget Ray Tracing Entry Point: This card lets you experience ray tracing without paying premium prices. The 12GB VRAM is also future-proof for texture-heavy games. Light Creative Work: Video editing, 3D modeling (Blender), and photo editing benefit from CUDA acceleration. Good for a secondary workstation or entry-level build. Not ideal for: Native 4K gaming at max settings or VR with very high refresh rates. Also lacks DLSS 3 Frame Generation (RTX 40-series exclusive).
Things to Consider
The EVGA RTX 3060 XC is a solid performer, but it has limitations. Its boost clock of 1882 MHz is factory-set and not the highest among RTX 3060 cards ??some AIB partners offer higher-clocked versions. The 192-bit memory bus, while sufficient for 1080p, can become a bottleneck in memory-bandwidth-intensive scenarios at higher resolutions. Power supply planning is important: while 550W is the minimum, a quality 650W unit is recommended for transient spikes and future upgrades. The card's dual-fan cooler is effective but not completely silent under load, though fan curves can be adjusted. Competitors include the AMD Radeon RX 6600 XT and RX 6650 XT, which offer similar rasterization performance at a slightly lower price. However, NVIDIA's ecosystem (DLSS, ray tracing, CUDA) and superior driver support for creative apps give the RTX 3060 an edge for certain users. ## FAQ
Q: What are the exact dimensions of this EVGA RTX 3060 XC? A: The card measures approximately 201.5mm in length, 111.5mm in height, and occupies two expansion slots. Always check your case's maximum GPU length before purchase. Q: Can I use this card for VR gaming? A: Yes, it can run most VR titles smoothly at default settings. For high-end headsets or very demanding VR experiences, consider a step up to an RTX 3070 or RTX 4060. Q: Does the EVGA RTX 3060 XC support NVIDIA G-Sync? A: Yes, it fully supports G-Sync (and G-Sync Compatible monitors) over DisplayPort. HDMI G-Sync is also supported on some displays. Q: Is the metal backplate purely cosmetic? A: No, the full metal backplate provides structural support, prevents PCB flexing, and aids in heat dissipation by allowing heat to spread across the back of the card.
