This article covers ASUS ROG Strix GeForce RTX 4060 Ti OC Edition ゲーミンググラフィックスカード (PCIe 4.0.

Overview

The ASUS ROG Strix GeForce RTX 4060 Ti OC Edition 16GB is a premium mid-range graphics card built on NVIDIA's Ada Lovelace architecture. It packs 16GB of GDDR6 memory, DLSS 3 with frame generation, and third-gen RT cores for solid ray tracing performance. This card stands out with its factory overclock: 2745MHz in OC mode and 2715MHz in default mode. The massive 3.1-slot Axial-tech cooler, combined with a vented backplate, keeps temperatures under control even during extended gaming sessions. It's an excellent choice for smooth 1440p gaming, and can handle 4K with DLSS enabled. The 16GB frame buffer gives it an edge in VRAM-heavy titles and creative workloads.

Compatibility Guide

The GPU uses a PCIe 4.0 x8 interface. It works in PCIe 3.0 slots, but for optimal performance, a PCIe 4.0 motherboard is recommended. Form factor: 3.1-slot, approximately 336mm long and 140mm wide. Most ATX mid-tower cases will fit, but check your case's GPU length clearance, especially in smaller MicroATX or Mini-ITX builds. Power: Two 8-pin PCIe power connectors are required. A 550W PSU is the minimum, but 650W or higher is recommended for headroom. * Outputs: One HDMI 2.1a (supports 4K 120Hz) and three DisplayPort 1.4a.

Product Info

The GPU is NVIDIA GeForce RTX 4060 Ti with 4352 CUDA cores, 34 RT cores, and 136 Tensor cores. The 16GB GDDR6 memory runs on a 128-bit bus, providing 288 GB/s bandwidth. Market positioning: upper mid-range. It sits below the RTX 4070 series in price but offers double the VRAM of the standard RTX 4060 Ti 8GB, making it ideal for VRAM-sensitive users. TDP: 165W Boost clock: 2745MHz (OC) / 2715MHz (default) Cooling: 3x Axial-tech fans (0dB mode), large fin array, vented metal backplate Extras: Aura Sync RGB, dual BIOS, GPU Tweak III software

Best Use Cases

1440p 60–120fps gamers: Ray tracing enabled with DLSS 3 delivers smooth frame rates. 16GB VRAM allows max texture quality without stuttering. Content creators: 16GB VRAM helps with 8K video editing, 3D rendering, and AI workloads. CUDA acceleration is widely supported. VRAM-conscious buyers: This card future-proofs against upcoming games that demand more than 8GB, outperforming the cheaper 8GB variant and many AMD alternatives in memory-heavy scenarios. Not for: Those targeting 4K 144fps in AAA titles should look at RTX 4070 Super or higher. Also, users with compact cases need to verify physical clearance before purchase.

Things to Consider

Physical size: 336mm length and 3.1-slot width are substantial. Double-check your case's maximum GPU length and ensure adjacent PCIe slots are not blocked. Power supply: Requires two 8-pin connectors. Most modern 650W PSUs have them, but older units may need cable adapters or an upgrade. Price premium: The 16GB version costs roughly 5000–8000 JPY more than the 8GB model. Evaluate whether your workload actually benefits from the extra memory. Competition: AMD Radeon RX 7700 XT (12GB) and RX 7800 XT (16GB) offer alternative options, often with better raw performance per dollar if ray tracing is not a priority. ## FAQ
Q: Can I use this card with a PCIe 3.0 motherboard? A: Yes, it will work. However, the RTX 4060 Ti uses a PCIe 4.0 x8 interface, which on a PCIe 3.0 slot runs at x8 3.0 (~8 GB/s). This may cause a small performance hit (2–5%) in some games, but it's generally fine for most users. Q: Is 16GB VRAM overkill for 1080p gaming? A: For 1080p, it's more than enough, but not overkill. It allows you to use max texture settings and future-proofs for games that may exceed 8GB even at 1080p. If you mainly play competitive shooters at low settings, the 8GB version will save you money. Q: Should I choose this or an RTX 4070? A: The RTX 4070 is about 15% faster in raw rendering and has 12GB VRAM (with wider memory bus). If the price difference is under $100 (JPY 15,000), the 4070 is a better value. If you need more VRAM for creative work or modded games, the RTX 4060 Ti 16GB is the smarter choice.

Product Disclosure (Amazon)

  • Manufacturer: ASUS
  • Seller: New Oriental Technology
  • Fulfilled by: New Oriental Technology
  • ASIN: B0CC38KSGH
  • Note: This article covers a manufacturer-made product based on Amazon listing details.
