Overview

MSI's GeForce RTX 4070 SUPER 12G GAMING X SLIM/A is a graphics card that packs high-end performance into a surprisingly compact 2-slot design. Measuring just 125mm in depth, it's significantly shorter than many RTX 4070 SUPER cards, making it ideal for builds where space is tight. The card features three TORX FAN 5.0 fans and MSI's TRI FROZR 3 thermal system, which combine to keep the GPU cool even under sustained loads. With 7168 CUDA cores, a boost clock of up to 2655MHz, and 12GB of GDDR6X memory running at 21Gbps, this card is built for smooth 1440p gaming and capable 4K experiences. Compared to the standard RTX 4070, it offers roughly 20% more performance for only about 10% more power draw, thanks to the SUPER architecture. As a mid-to-high-tier product, the GAMING X SLIM/A targets gamers and creators who want strong performance without needing a full-size card. It's especially well-suited for small-form-factor builds where traditional high-end cards simply won't fit.

Compatibility Guide

The card uses a PCI Express 4.0 x16 interface and is compatible with PCIe 3.0 slots, though bandwidth may be slightly reduced. Power delivery requires a single 12VHPWR (12+4-pin) connector; an adapter to two 8-pin PCIe power cables is included. MSI recommends a 650W power supply, but for systems with power-hungry CPUs, a 750W unit is advisable. Physical dimensions: 307mm length, 125mm width, 46mm height (2 slots). While it fits most mid-tower and full-tower cases, you must check your case's maximum GPU length—especially in compact cases that may have limits around 300mm. The 2-slot thickness is standard and won't obstruct adjacent PCIe slots in most ATX boards.

Product Info

Released in early 2024, the MSI GeForce RTX 4070 SUPER 12G GAMING X SLIM/A carries model number VD8749 and comes with a one-year manufacturer warranty in Japan. The GPU is an NVIDIA GeForce RTX 4070 SUPER with 7168 CUDA cores, base clock 1980MHz, and boost clock 2655MHz (via MSI Center Extreme Performance). Memory is 12GB GDDR6X over a 192-bit bus, with effective memory clock of 21Gbps. TDP is rated at 245W, and the recommended PSU is 650W or higher. Market positioning: solidly mid-high tier. It competes with cards like the ASUS Dual RTX 4070 SUPER and Gigabyte Windforce, but stands out for its compact dimensions and robust cooling solution.

Best Use Cases

1440p High-FPS Gaming: This card is a natural fit for 1440p monitors with 144Hz or higher refresh rates. Games like Overwatch 2, Call of Duty, and Cyberpunk 2077 run smoothly with high settings and ray tracing enabled. For 4K ultra settings without DLSS, consider a step up to RTX 4080 SUPER. Small Form Factor (SFF) Builders: The 125mm depth is a game-changer for SFF cases like the Cooler Master NR200P or Lian Li TU150. It allows for better airflow and easier cable management compared to longer cards. However, verify total length; some very compact cases (e.g., 10L or less) may still be too small. * Content Creators on a Budget: With 12GB VRAM and 7168 CUDA cores, video editing in Premiere Pro or DaVinci Resolve gets a significant boost. For 3D rendering in Blender, the card performs admirably for medium-complexity scenes. Heavy 4K RAW workflows or complex animations may require more VRAM.

Things to Consider

The 12VHPWR connector requires careful installation—ensure it's fully seated to avoid overheating. The included adapter is fine, but a native 12VHPWR PSU simplifies cabling. At 307mm long, this card is not for truly compact cases like the Fractal Design Terra or Dan Cases. Always measure before buying. Fan noise is present under load; while the Zero Frozr feature stops fans at idle, under gaming the triple fans can be audible. Adjusting the fan curve in MSI Center can help balance noise and thermals. Compared to the slightly more expensive RTX 4070 Ti SUPER, this card has less VRAM and fewer CUDA cores. If you plan to keep the card for 4+ years or do heavy creative work, the extra investment may be justified. ## FAQ
Q: Can I use this card with my PCIe 3.0 motherboard? A: Yes, it will work. You may see a very small performance hit (2-5%) in bandwidth-sensitive games, but for most users the difference is negligible. For best results, pair it with a PCIe 4.0-capable platform (Intel 12th gen or newer, AMD Ryzen 3000-series or newer). Q: Does the card include a 12VHPWR adapter? A: Yes, the box includes a 12VHPWR-to-dual 8-pin adapter cable. If your power supply has a native 12VHPWR port, you can use a single cable without the adapter, which looks cleaner. Q: Is this card good for 4K gaming? A: It's capable for 4K at medium-to-high settings, especially with DLSS enabled. For native 4K ultra at 60fps in the latest titles, you'll want a more powerful card like the RTX 4080 SUPER. However, for older or less demanding games, this card handles 4K very well.

Product Disclosure (Amazon)

  • Manufacturer: MSI
  • ASIN: B0CRZ64482
  • Note: This article covers a manufacturer-made product based on Amazon listing details.
