This article covers Kensington SD5600T 14-in-1 Thunderbolt 3 Dock USB-C.

Overview

The Kensington SD5600T is a 14-in-1 Thunderbolt 3 docking station designed to turn a single USB-C port on your laptop into a full desktop workspace. With 40 Gbps throughput, it can drive two 4K monitors at 60 Hz, connect to a wired Gigabit Ethernet network, and charge the host laptop with up to 100W of Power Delivery 3.0 — all simultaneously. The dock ships with a 0.8-meter Intel-certified Thunderbolt 3 cable, so you don't need to hunt for a compatible cable out of the box. It positions itself as a premium all-in-one solution for professionals who need maximum port variety without sacrificing performance or display quality.

Connectivity & Compatibility

On the video side, the SD5600T provides two HDMI 2.0 ports and two DisplayPort 1.2 ports. When connected via Thunderbolt 3, you can run two 4K displays at 60 Hz; when used with a USB-C host, the dock supports a single 4K@60Hz display or dual 1080p@60Hz. For data and storage, it includes one USB-C Gen2 port (10 Gbps, 5V/1.5A charging) on the front and six USB-A ports — one Gen2 (10 Gbps) on the front and five Gen1 (5 Gbps) on the back. Both the full-size SD card slot and the microSD slot support UHS-II SD 4.0, a boon for photographers transferring large RAW files. A Gigabit Ethernet port (up to 1 Gbps) and a 3.5 mm combo audio jack round out the wired connections. Compatibility covers a wide range of hosts: Thunderbolt 3 laptops (macOS 10.15+, Windows from brands like Lenovo, Dell, HP, ASUS, Razer), Thunderbolt 4 devices at Thunderbolt 3 speeds, USB-C notebooks, and Microsoft Surface devices (Pro 8/7, Laptop 3, Book). Important caveat: Apple MacBooks with M1, M2, or M3 (non-Pro/Max) chips are limited to a single external display due to Apple's chipset architecture. If you own one of those and need dual 4K, Kensington recommends the SD4780P dock (part number K33620NA).

Product Info

First released in 2020, the SD5600T sits in the upper-mid range of the Thunderbolt 3 dock market, justified by its generous port count and high power delivery. The included 170W power supply delivers up to 100W of USB-C PD to the host laptop — enough to charge a 16-inch MacBook Pro or other power-hungry notebooks. The dock itself is VESA-mountable (mounting base included) and can be oriented horizontally or vertically. Kensington backs it with a three-year limited warranty and lifetime free technical support.

Best Use Cases

MacBook Pro users (M1 Pro/Max or later) who need two 4K displays at 60 Hz from a single cable — ideal for video editors, developers, and designers using external monitors for extended desktop space. Windows laptop owners in an office or home-office setup where a wired Gigabit Ethernet connection is preferred for stability, and multiple USB peripherals (mouse, keyboard, external SSD, printer) need to stay connected permanently. * Anyone wanting a clean desk with minimal cable clutter: the VESA mount hides the dock behind a monitor, and a single Thunderbolt 3 cable handles charging, video, data, networking, and audio.

Product Disclosure (Amazon)

  • Manufacturer: Kensington
  • Seller: gmj3
  • Fulfilled by: gmj3
  • ASIN: B08H4WHQ2N
  • Note: This article covers a manufacturer-made product based on Amazon listing details.
