Overview

The j5create JCC154G USB-C to HDMI Cable has a USB-C male and a USB Type-A male (for charging) on one end and an HDMI male on the other. According to the manufacturer's official product page, the maximum display resolution is 3840 x 2160 and the maximum refresh rate is 60 Hz.

The official page lists a maximum data transfer rate of 18 Gbps and audio as "2.1 via HDMI".

The number of supported displays is 1, and wide screen is listed as supported (Yes).

Compatibility Guide

The connection details on the official page are: connector A is one USB-C male plus one USB Type-A male for charging, and connector B is one HDMI male. That means the source needs a USB-C port and the display needs an HDMI input.

The two cables differ in length: the USB-C cable is 1.83 m.

(180 cm) and the USB Type-A cable is 1.22 m.

(120 cm). Because the lengths differ, the device and the charging port can be placed at different distances.

Whether a given USB-C port supports video output is not stated on the official page. Check your device's own specifications.

Product Info

rmation

The items below are the ones listed on the manufacturer's official page.

Item Official listing
Connector A 1 - USB-C® Male; 1 - USB™ Type-A Male for Charging
Connector B 1 - HDMI™ Male
Max display resolution 3840 x 2160
Max display refresh rate 60 Hz
Max data transfer rate 18 Gbps
Audio channel 2.1 via HDMI™
Displays supported 1
Cable length USB-C® cable: 1.83 m. (180 cm); USB™ Type-A cable: 1.22 m. (120 cm)
Cable jacket type PVC
Cable shield type Aluminum
Enclosure type Aluminum
Color Gray & White
Warranty 1 Year Limited

The table copies the official page's wording as is. The jacket is listed as PVC while the shield and enclosure are listed as Aluminum, so the product has an aluminum enclosure by the maker's description.

The official page also gives dimensions and weight: width 66 mm. (65.6 mm), height 20 mm.

(20.2 mm), depth 11 mm.

(11.6 mm), and weight 62.5 g.

For conditions of use, operating temperature is 0 to 45°C and storage temperature is -10 to 71°C. Humidity is listed as under 85 percent, non-condensing, for both operation and storage.

Who It Suits

  • People who can run both a USB-C port and a USB Type-A charging port near the source, since the official layout uses both connectors on the same end.
  • People whose source and charging power sit at different distances, because the USB-C side is 1.83 m. (180 cm) and the USB Type-A side is 1.22 m. (120 cm).
  • People who need only one display, since the official page lists 1 supported display.

Before You Buy

  • Check your device's specifications to confirm its USB-C port can output video. The official page does not state this.
  • The USB Type-A end is listed for charging, so make sure you have a USB Type-A power port you can use.
  • The official page lists 1 supported display. If you want to drive several displays, look at a different setup.
  • The operating temperature is listed as 0 to 45°C, so think about where the cable will be used.
  • Check the sales page for current price and stock.

FAQ

Q. How many displays can it drive at once?

A. The manufacturer's official page lists "displays supported" as 1.

Q. Does it carry audio over HDMI?

A. The audio channel entry on the official page reads "2.1 via HDMI™".

Q. Is there a warranty?

A. The official page states "1 Year Limited".
