The FANATEC CSL Elite Pedals V2 brings a real load cell brake down to the price tier just above entry-level. The brake measures up to 90kg of force (the sensor itself is rated beyond 200kg), while throttle and clutch use non-contact Hall sensors, so they do not drift the way worn potentiometers do.
This article goes past the spec sheet to who should buy it and who should not.
Overview
This is Fanatec's mid-range 3-pedal set: clutch, brake and throttle. The headline feature is the brake, which reads pressure rather than travel.
Real cars are braked by force, not by distance, so moving to a load cell changes how repeatable your braking becomes far more than any throttle upgrade would.
The target buyer is clear: someone who has put in laps on the 2-pedal set bundled with an entry wheel and now finds brake release and trail braking inconsistent. If you race casually a few times a month, a rigid rig or pedal stand will improve your lap times more than these pedals will.
As of June 2026 the Amazon.co.jp listing showed 70 reviews at 4.6 out of 5 (roughly 92% positive).
The sample is small, but consistently strong for this price class.
Connectivity & Compatibility
There are two connection paths. Connecting directly to a compatible Fanatec base with the RJ12 cable is recommended: lower latency, simpler wiring.
On PC you can also run the pedals standalone over USB.
| Setup | Works? | What you need |
|---|---|---|
| Windows PC (standalone) | Yes | USB only, no base required |
| Windows PC (via base) | Yes | Fanatec base + RJ12 (recommended) |
| PS5 / PS4 | Conditional | A PlayStation-licensed Fanatec base is mandatory |
| Xbox Series X|S / One | Conditional | An Xbox-licensed Fanatec wheel is required |
"Conditional" means the pedals will not work on their own. This is the single most common misunderstanding: console players buy the pedals alone and nothing is detected.
Fanatec's console licensing lives in the base or wheel, and the pedals sit underneath that licensed device.
Physically, a load cell brake is a poor match for pedals sitting loose under a desk. Once you push 40kg the set slides forward.
Plan on a non-slip pedal stand at minimum, ideally bolting to a rigid rig or cockpit. Pedal spacing is adjustable laterally along the heel rest and the rubber covers are removable, so fine-tuning for foot size or shoes is easy.
Product Info
| Item | Detail |
|---|---|
| Pedals | 3 (clutch / brake / throttle) |
| Brake sensor | Load cell, measures to 90kg, sensor rated 200kg+ |
| Throttle / clutch | Non-contact Hall effect |
| Connection | RJ12 to a Fanatec base, or USB standalone on PC |
| Brake tuning | Tool-free; Shore 65/75/85 elastomers + metal spring |
| 2-pedal mode | Yes (remove the clutch) |
| Position adjust | Lateral along the heel rest |
| Materials | Cast and machined aluminum, powder coated |
| Pedal covers | Rubber, removable |
Pedal arms, faces and heel rest are cast and machined aluminum with a durable powder coat, and a rear support brace adds rigidity. Coming from plastic entry pedals, the absence of flex is the first thing you notice.
The brake uses a custom load cell with a tool-free elastomer stack. Higher Shore numbers are stiffer and need more force for the same travel.
Start at 65; if you bottom out the pedal, move to 75, then 85 if you want a heavy GT3-style leg. A metal spring is included for an even firmer preload.
Prices at capture time — all of these move, so check the listing before you buy:
- Amazon (Japan): ¥38,000 as captured 27 Aug 2026
- Amazon (earlier capture): ¥45,000 as captured 1 Jun 2026
- eBay (US listing): $329.99 as captured 15 Jul 2026
The same listing moved ¥45,000 to ¥38,000 in about three months. Treat the numbers above as a range, not a budget line, and if you are not in a hurry, waiting for a sale is worth real money.
Reviews stood at 70 with 4.6/5 as of June 2026.
Setup That Actually Matters
Three things to do on day one. First, mount it — bolt the set to a rig or stand and confirm nothing moves.
Second, pick the elastomer using the 65 to 75 to 85 order above, choosing the stiffness where full braking lands just short of your maximum. Third, calibrate in software so 100% brake output corresponds to a force you can repeat every lap.
The classic mistake is stacking the stiffest elastomer with a high output ceiling, then never reaching the ABS threshold. A load cell rewards consistency, not brute strength.
Start soft and work up.
How It Compares
At this price you are also looking at load cell sets like the Thrustmaster T-LCM, or the 3-pedal sets bundled with MOZA direct drive kits. Bundles win on total outlay because you get a base and wheel too; standalone pedals win on build and adjustment range.
The strongest case for the CSL Elite Pedals V2 is that you already own a Fanatec base. RJ12 keeps everything on one device tree, and the pedals survive future base or wheel upgrades.
If you run another brand's base and will connect over USB on PC, that ecosystem advantage disappears — compare purely on build, tuning range and price.
Best Use Cases
- You use potentiometer 2-pedal sets and your braking is inconsistent lap to lap
- You already own a Fanatec base (Gran Turismo DD Pro and similar) and want to upgrade only the pedals
- You have a rig or cockpit and can bolt the pedals to something rigid
- You drive manual-shift or rally titles and want a clutch — or you can remove it for a 2-pedal layout
- You move between PC, PlayStation and Xbox, keeping the licensing requirements above in mind
Before You Buy
The pedals alone do nothing on a console. PS5/PS4 needs a PlayStation-licensed Fanatec base; Xbox needs an Xbox-licensed Fanatec wheel.
Buying on the strength of "PS5 compatible" and then returning an undetected set is the most common failure here.
Without rigid mounting you lose the benefit. A 90kg measurement range only means something if your setup can absorb 90kg.
Pedals braced against a desk leg slide the moment you press hard, and you end up modulating travel again. Budget for mounting separately.
Expect an adjustment period. Braking by force uses your leg differently than braking by travel.
Losing a few tenths for the first races is normal; drop one elastomer step softer and prioritize repeatability over peak force.
Prices swing widely. The same page differed by ¥7,000 between June and August 2026 captures, and overseas listings (eBay at $329.99 in July 2026) can lose their advantage once duties, shipping and warranty handling are counted.
Listing metadata is not always right. Amazon manufacturer, model and compatibility fields often mix data from sibling models.
Since V1 and V2, and 2-pedal and 3-pedal variants, share shelf space, confirm from the product images and title that you are buying the V2 3-pedal set.
Who should skip it. Casual racers who run a few sessions a month, players who prefer light controller-style inputs, and anyone racing at a desk for short sessions.
If you are committed to a Logitech or Thrustmaster console wheel, that brand's own load cell pedals will keep your setup simpler.
FAQ
Q. PC only — do I need a Fanatec base?
A. No. USB standalone works. If you own a base, RJ12 is still preferable for latency and setup.
Q. How hard am I supposed to press? A.
The spec measures to 90kg and the sensor is rated past 200kg, but set your ceiling to the force you can repeat every lap. Chasing 90kg is not the goal.
Q. Which elastomer should I use? A.
Shore 65, 75 and 85 plus a metal spring are included. Run 65 first and go stiffer if you bottom out.
No tools needed.
Q. Can the clutch be removed?
A. Yes, it converts to a 2-pedal layout, which also frees up footwell space.
Q. What does it cost? A.
At capture: ¥38,000 on Amazon Japan (27 Aug 2026), ¥45,000 in an earlier 1 Jun 2026 capture, and $329.99 on a US eBay listing (15 Jul 2026).
Check the listing for current pricing.
