This article covers Club3D DisplayPort 1.2 to 3 HDMI Multi-Display MST Hub (CSV-5300H) by CLUB3D.

Overview

The Club3D CSV-5300H is a DisplayPort 1.2a MST (Multi-Stream Transport) hub that splits a single DisplayPort input into three independent HDMI outputs. It enables you to connect up to three HDMI monitors from a DP-only laptop or desktop, with each output supporting up to 2560×1600 @ 60Hz in MST mode. This makes it a practical tool for expanding your workspace or setting up multi-monitor presentations. A mini DisplayPort cable is included in the box for immediate connectivity.

Connectivity & Compatibility

The hub complies with DisplayPort 1.2a and is backward compatible with DP 1.1a. Input is via standard DisplayPort (male) or the included mini DP cable. The three HDMI outputs support HDCP 2.0, EDID pass-through, and resolutions up to 2560×1600 per display in MST mode (1920×1080 max in SST mode). It works with any device that has a DisplayPort output, including desktop PCs, laptops, and workstations. Note that the HDMI ports are limited to HDMI 1.4b bandwidth; 4K 60Hz is not supported on this hub.

Product Info

The Club3D CSV-5300H (model CSV-5300H) has been on the market since around 2014 but remains available through select retailers. Its price hovers around ¥67,772 in Japan, reflecting its niche status. The hub measures 325×105×9 mm and weighs roughly 120 g (cable included). It comes with a mini DisplayPort cable and a quick-start guide. The warranty is typically 2 years from Club 3D. In terms of market positioning, this is a mid-to-high-end MST hub from the DP 1.2 era, offering reliable three-screen expansion for legacy DP setups.

Best Use Cases

This hub is ideal for professionals who need to connect three HDMI monitors to a laptop that only has a DisplayPort output. For example, financial analysts or designers working from multiple screens can set up a three-monitor configuration without upgrading their PC. It also suits users who have an older desktop PC with DisplayPort 1.2 and want to reuse three HDMI monitors. However, if you need higher bandwidth (e.g., 4K @ 60Hz or DP 1.4 features), look for a newer MST hub or a USB-C dock with DisplayPort Alt Mode.

Product Disclosure (Amazon)

  • Manufacturer: Club 3D
  • Seller: DGMオンライン
  • Fulfilled by: DGMオンライン
  • ASIN: B00O5M2WDW
  • Note: This article covers a manufacturer-made product based on Amazon listing details.
