This article covers 【限定】 ASRock マザーボード B760M Pro-A.

Overview

The ASRock B760M Pro-A/D4 WiFi is a Micro-ATX motherboard built around the Intel B760 chipset and LGA1700 socket. Designed for 12th and 13th Gen Core processors, it takes the practical route by supporting DDR4 memory, which keeps overall build costs lower than DDR5 alternatives. Retailing for under $150 (around ¥19,800 in Japan), this board packs a surprising number of modern amenities: Wi-Fi 6E, Bluetooth 5.3, 2.5 Gigabit LAN, and two PCIe 4.0 M.2 slots. It strikes a solid balance between price and features, making it an attractive option for first-time builders and budget-conscious enthusiasts. On the video output side, it includes HDMI 2.1 (TMDS compatible) and DisplayPort 1.4 with DSC, allowing 4K @ 60Hz or even 8K @ 60Hz using the processor’s integrated graphics. If you’re building a compact office PC or a casual media center without a discrete GPU, this board handles those tasks admirably.

Compatibility Guide

Socket & CPU: LGA1700, compatible with Intel 12th Gen (Alder Lake) and 13th Gen (Raptor Lake) Core processors. While 14th Gen Raptor Lake Refresh also uses LGA1700, official support is not guaranteed without a BIOS update. Stick with 13th Gen for a pain-free experience. Memory: Four DDR4 DIMM slots, dual-channel, up to 128 GB. Native DDR4-3200, overclockable to 5333+ MT/s via XMP 2.0. Perfect if you already own DDR4 sticks or want to save over DDR5 pricing. Form Factor: Standard Micro-ATX (244 mm × 244 mm). Fits most Micro-ATX cases. Two PCIe 4.0 x16 slots (top slot is the primary GPU slot) and one PCIe 4.0 x1 slot. The second x16 slot runs at x4 electrically in most configurations, so it’s best suited for storage controllers or capture cards. Storage: Two M.2 slots (both PCIe Gen4 x4), four SATA3 ports. No bundled heatsinks for the M.2 slots — plan to buy aftermarket heatsinks if you install fast Gen4 NVMe drives. Power: Standard 24-pin ATX + 8-pin EPS. Recommended PSU wattage: 550–650W for a typical mid-range gaming build.

Product Info

The ASRock B760M Pro-A/D4 WiFi launched in early 2024 as part of the B760 lineup. It positions itself in the entry-to-mid tier segment, delivering modern connectivity (Wi-Fi 6E, 2.5G LAN) while keeping memory costs low via DDR4 support. The VRM implementation is 7+1+1 phases with Dr.MOS — sufficient for Core i5 and i7 processors, though pushing an i9 with heavy overclocking may stress the power delivery under sustained loads. Audio is handled by the Realtek ALC897 codec (entry-level but adequate for most users). The network section combines a Dragon 2.5G LAN controller with the Killer AX1690i Wi-Fi 6E module (also handles Bluetooth 5.3). Warranty is three years via ASRock’s Japanese authorized distributors.

Best Use Cases

First-time PC Builder Micro-ATX is the most forgiving form factor for beginners: not too cramped like Mini-ITX, yet smaller than full ATX. Built-in Wi-Fi means no separate wireless card purchase, and the BIOS is straightforward. Great pairing with a Core i5-12400 or i5-13400. Budget 1080p Gaming Rig Combine this board with a Core i5-13400F and a GeForce RTX 4060 or Radeon RX 7600. The DDR4 memory savings can be redirected to a better GPU. The PCIe 4.0 x16 slot won’t bottleneck these mid-range cards. Compact Office / Home Server With the integrated GPU outputs and dual M.2 slots, this board is ideal for a headless NAS or a quiet office PC inside a small Micro-ATX case. The 2.5G LAN helps with file transfers over a local network. Who should NOT buy this? If you need DDR5 memory support, PCIe 5.0 M.2 or GPU slots, or plan to run a heavily overclocked Core i9-13900K at full load for extended periods, you’re better off with a higher-end Z790 board.

Things to Consider

  • No DDR5, no PCIe 5.0: This board uses DDR4 and is limited to PCIe 4.0. If you’re building for future-proofing with upcoming graphics cards or SSDs that might leverage PCIe 5.0, consider other options. - M.2 heatsinks not included: Gen4 NVMe drives can reach high temperatures under sustained writes. Purchase aftermarket heatsinks for the best performance and longevity. - Audio codec is basic: Realtek ALC897 is acceptable for gaming headsets and desktop speakers, but audiophiles using high-impedance headphones will want an external DAC. - Only one 8-pin EPS connector: Not an issue for most builds, but extreme overclocking with top-tier CPUs may need more power input. ## FAQ
    Q: Will this board work with an Intel Core i3-12100? A: Yes, the B760M Pro-A/D4 WiFi supports all LGA1700 12th and 13th Gen processors, including the i3-12100 and i5-12400. No BIOS update is required for those chips. Q: Can I use an RTX 4070 with this motherboard? A: Absolutely. The primary PCIe x16 slot runs at PCIe 4.0 x16, which is fully compatible with any modern graphics card. Just ensure your case has enough clearance for the card’s length. Q: Does this motherboard support Windows 11? A: Yes, it supports
