This article covers ASRock マザーボード B650E Steel Legend WiFi AMD Ryzen 7000 シリーズ CPU対応 (Soket AM5) B650E ATX マザーボード 【国内正規代理店品】.

Overview

The ASRock B650E Steel Legend WiFi is an ATX motherboard built for AMD Ryzen 7000 series processors on the AM5 socket. Part of the popular Steel Legend lineup, it features a distinctive white-themed military-style design. Despite being based on the mid-range B650E chipset, it comes with PCIe 5.0 support on primary expansion slots and one M.2 slot. The 16+2+1 phase Dr.MOS power delivery system is robust enough to handle Ryzen 9 flagship CPUs without breaking a sweat. Priced around ?28,000?30,000, this motherboard offers exceptional value. It includes dual LAN (2.5GbE + 1GbE), built-in Wi-Fi 6E and Bluetooth 5.2, and full DDR5 memory support (up to 128GB). Two PCIe 5.0 x16 slots and three M.2 slots (one PCIe 5.0, two PCIe 4.0) provide ample expansion for modern GPUs and SSDs.

Compatibility Guide

Socket: AM5, compatible with all Ryzen 7000 series processors (Ryzen 5/7/9). Memory: 4x DDR5 DIMM slots, max 128GB, supports XMP/EXPO. Form factor: standard ATX (305?244 mm). Requires 24-pin ATX main power + 8-pin + 4-pin EPS12V CPU power. Recommended PSU: 650W or higher for Ryzen 7/9 builds. Storage: 3x M.2 slots (1x PCIe 5.0 x4, 2x PCIe 4.0 x4) with heatsinks included; 2x SATA 6Gbps. The first M.2 slot shares bandwidth with the primary PCIe x16 slot in some configurations, so check the manual if populating both. GPU clearance is generally fine as long as your case supports ATX boards.

Product Info

Released late 2022, the ASRock B650E Steel Legend WiFi sits in the entry-to-mid tier AM5 market but punches above its weight with high-end features. The B650E chipset uniquely offers PCIe 5.0 lanes from the CPU, unlike standard B650. The 16+2+1 phase VRM is overbuilt for the price bracket, making this board suitable for even 170W+ CPUs. Warranty is typical 3 years. Available via major online and retail channels.

Best Use Cases

Gamers: Pair with a Ryzen 7 7800X3D and PCIe 5.0 GPU/SSD for a future-proof gaming rig. The dual LAN and Wi-Fi 6E ensure low-latency online gaming. Multiple M.2 slots let you add fast game libraries. Creators: The robust VRM delivers stable power for multi-core rendering or video encoding. DDR5 support provides high bandwidth for large project files. PCIe 5.0 slot allows fast data transfer with compatible NVMe SSDs. * Value-conscious builders: This board offers near-flagship features like PCIe 5.0 and strong power delivery at a mid-range price. It is an ideal foundation for a high-performance PC on a budget.

Things to Consider

The B650E chipset has fewer USB and SATA ports than X670/X670E boards. The back panel includes only one USB 3.2 Gen2?2 Type-C?and a limited number of USB 3.2 Gen2 Type-A ports. If you need many peripherals, a USB hub may be necessary. Only the primary M.2 slot is PCIe 5.0; the other two are PCIe 4.0. If you intend to run multiple high-speed SSDs, plan accordingly. Also, the VRM heatsink is compact; in poorly ventilated cases, VRM temperatures can rise under extended heavy loads. Competitors like the MSI MAG B650 TOMAHAWK WiFi or Gigabyte B650 AORUS ELITE AX offer similar features at comparable prices. The ASRock stands out with its unique white design, dual LAN, and Steel Legend aesthetic.

Product Disclosure (Amazon)

  • Manufacturer: ASRock
  • Seller: ショップ ラズベリー [適格請求書発行事業者登録済]
  • Fulfilled by: Amazon
  • ASIN: B0BH4MNQXV
  • Note: This article covers a manufacturer-made product based on Amazon listing details.
