This article covers Synology DS1522+ 5ベイ DiskStation NAS (AMD Ryzen R1600 8GB Ram 4xRJ-45 1GbE LAN-Port) 5ベイ 60TB バンドル 5X 12TB Seagate IronWolf.

Overview

The Synology DS1522+ is a 5-bay NAS designed for home users, creative professionals, and small to medium-sized businesses. Powered by an AMD Ryzen R1600 processor and 8GB of RAM (expandable up to 32GB), it offers a solid balance of performance and expandability. The unit supports up to 15 drives when paired with the optional DX517 expansion unit, and can be upgraded with 10GbE networking and NVMe SSD caching for faster data access. Running Synology's DiskStation Manager (DSM), the DS1522+ provides an intuitive interface for file management, backup, synchronization, and surveillance. It handles more concurrent users and demanding workloads than its predecessor, making it a versatile choice for growing data needs.

Connectivity & Compatibility

The rear panel features four 1GbE RJ-45 LAN ports, with an optional E10G22-T1-Mini add-on card enabling 10GbE connectivity. Two USB 3.2 Gen 1 ports are on the back, plus one on the front for easy external drive access. An eSATA port allows connection to the DX517 expansion unit, increasing total drive bays to 10. Drive bays accept 3.5-inch SATA HDDs/SSDs (6Gbps) with hot-swap support. Two internal M.2 NVMe SSD slots (2280) are available for caching, boosting read/write performance for frequently accessed data. The system supports Btrfs and ext4 file systems, enabling snapshots, data integrity checks, and advanced volume management.

Product Info

Released in June 2022, the Synology DS1522+ sits in the mid-to-high-end NAS category. Its 5-bay design and expansion options make it ideal for SOHO and small office environments that anticipate growth. While the standard 1GbE ports are sufficient for everyday file sharing, adding 10GbE or NVMe cache unlocks higher throughput for demanding workflows. The standard warranty is 3 years (extendable). The package includes the unit, power adapter, power cord, two RJ-45 LAN cables, quick installation guide, and screws.

Best Use Cases

Small office or creative team: Centralize file sharing, version control, and backups for multiple users. DSM's granular permission system lets you control access per user or group. Home user with large media collections: Store photos, videos, and documents, and access them remotely via Synology Photos or Drive apps on smartphones and tablets. * Surveillance system: Use the included 2 free Surveillance Station licenses to record and manage IP cameras (up to 40 cameras total). If you only need basic file serving, a 2-bay model like the DS224+ may be more cost-effective. Also, note that 10GbE requires an optional add-on card, which adds to the total cost.

Things to Consider

Memory is 8GB standard but expandable to 32GB — using non-Synology RAM may cause compatibility issues. 10GbE requires a separate add-on card (e.g., E10G22-T1-Mini). The built-in 1GbE ports may bottleneck large file transfers. NVMe SSD cache can be read-only or read-write — the cache SSDs are not usable as system storage, so you still need HDDs/SSDs for your storage pool. Expansion unit DX517 requires matching firmware between the main unit and the expansion. * Power consumption is around 30W under load, 20W idle — relatively low, but 24/7 operation adds to electricity costs. ## FAQ
Q: How do I access this NAS from a Windows PC? A: Connect both devices to the same network, then open a web browser and go to find.synology.com, or install the Synology Assistant desktop app. For file sharing, use SMB/CIFS protocol and map a network drive in File Explorer. Q: Is upgrading to 10GbE worth it? A: Yes, if multiple users frequently transfer large files (e.g., video editing projects, VM images). The speed improvement is dramatic, but you'll also need a 10GbE switch and compatible NICs on client machines, increasing overall investment. Q: Does this model support hardware transcoding for Plex? A: No, the DS1522+ lacks hardware transcoding. For real-time video conversion in Plex or Video Station, consider a model with an Intel CPU (e.g., DS923+ or a newer unit).
