This article covers NZXT H510 Elite 前面+側面ガラスパネル RGB LED発光&ファン制御機能搭載 [ White & Black ] CA-H510E-W1.

Overview

The NZXT H510 Elite (model CA-H510E-W1) is a mid-tower PC case that puts tempered glass front and center. Both the front and side panels are made of toughened glass, giving you a clear view of your components and the pre-installed RGB LED strip. It's a case that appeals to builders who want their system to look as good as it performs. Inside, the included Smart Device V2 controller handles both fan speed and RGB lighting simultaneously. Two Aer RGB 2 140mm fans are pre-installed at the front and one Aer F 120mm at the rear, so you can start building and enjoying the lighting effects right out of the box. The integrated LED strip along the top edge adds a subtle glow that ties the whole look together. With support for GPUs up to 381mm and CPU coolers up to 165mm, the H510 Elite can accommodate almost any high-end component. It also supports up to a 280mm radiator at the front, making it suitable for liquid cooling builds. The case is available in a White & Black color scheme that stands out without being too flashy.

Compatibility Guide

The H510 Elite supports ATX, Micro ATX, and Mini-ITX motherboards. The power supply is mounted in a bottom shroud, which helps keep cable clutter out of sight. Most standard ATX PSUs will fit without issues. Graphics card clearance is generous at 381mm, so you can install even the largest RTX 4090 or RX 7900 XTX cards. CPU cooler height is maxed at 165mm, which covers most tower air coolers but may exclude the very tallest heatsinks like the Noctua NH-D15 (which is 165mm exactly, but some users report a tight fit). Radiator support: front up to 280mm (60mm thick), rear up to 120mm. The top panel does not support radiator mounting, so if you want a 360mm AIO, you'll need a larger case. The front panel has limited side intake vents, so airflow is more restricted compared to mesh designs.

Product Info

Released in 2019, the NZXT H510 Elite remains a popular choice for builders who prioritize aesthetics. It sits in the mid-to-upper mainstream tier, offering a premium tempered-glass look and integrated RGB control at a relatively accessible price point. Warranty is 1 year from the date of purchase (receipt or invoice required). The case is widely available through , Newegg, and other major retailers. It weighs approximately 7.5 kg and measures 210mm W x 428mm D x 460mm H. Key features include the Smart Device V2 controller, pre-installed RGB LED strip, and two Aer RGB 2 140mm fans. The cable management area behind the motherboard tray has 19-23mm of depth, allowing for tidy routing of even thick PSU cables.

Best Use Cases

RGB enthusiasts and first-time builders The Smart Device V2 makes it easy to control lighting and fans through CAM software without needing additional controllers. If you want a clean, illuminated build with minimal effort, this case delivers. It's also a great choice for someone who wants to show off their components through the glass panels. Mid-range to high-end gaming PCs Combined with a 280mm AIO cooler, the H510 Elite can handle the thermals of a Ryzen 7 or Core i7 paired with a high-end GPU. The tempered glass panels let you display your hardware proudly. However, if you plan to run an overclocked i9 or a 450W+ GPU, the restrictive airflow might become a concern. Builders who prefer a clean, minimalist look The cable management system is well-designed, with channels and Velcro straps to hide wires. The PSU shroud covers the bottom area, and the drive cages are tucked away. This case is ideal for those who want a neat interior without spending hours on cable routing. Not ideal for: - Users who want a mesh front panel for maximum airflow (consider the H510 Flow instead). - Those who want to mount a 360mm radiator (top or front) – not possible in this case. - Builders looking for the smallest possible footprint (it's a standard mid-tower).

Things to Consider

The H510 Elite's main drawback is its front airflow. The tempered glass panel has only narrow side vents, which can starve intake fans of fresh air, especially when using high-power components. If you're building a system with a high TDP CPU and a power-hungry GPU, the H510 Flow (mesh version) would perform better thermally. Also, the vertical GPU mount slots are included, but you need to purchase a riser cable separately. The case does not come with one. Additionally, the top panel does not support any radiator, so water cooling is limited to front mount (up to 280mm) or rear (120mm). Competitors to consider: Corsair 4000D Airflow (better airflow, similar price), Fractal Design Meshify C (better cooling, slightly smaller), and NZXT H510 Flow (same look with mesh front). If RGB control is a priority, the H510 Elite stands out, but for pure performance, there are better options. ## FAQ
Q: Can I install a 360mm radiator in this case? A: No. The front supports up to 280mm, and the

Product Disclosure (Amazon)

  • Manufacturer: NZXT
  • Seller: オーデイズオンライン☆30日間返金保証☆
  • Fulfilled by: Amazon
  • ASIN: B07V4R6ZGF
  • Note: This article covers a manufacturer-made product based on Amazon listing details.
