Overview

The FebSmart FS-HA-Pro is a PCIe x1 USB 3.0 expansion card that adds two USB-A ports on the rear bracket plus a 19-pin internal header for two more front-panel USB-A ports. It uses a Renesas uPD720201 host controller and delivers up to 5Gbps per port. The card's self-powered design draws 12V from the motherboard and provides up to 5V/2A per port, so no extra power cable is needed. This makes it a practical, budget-friendly upgrade for desktop PCs that need more USB 3.0 connectivity.

Connectivity & Compatibility

The FS-HA-Pro plugs into any PCIe x1, x2, x4, x8, or x16 slot. It is based on the PCIe 2.0 spec but works in PCIe 1.x, 3.x, and 4.x slots as well. On the software side, Windows 11, 10, and 8.x are plug-and-play; Windows 7 and older require manual driver installation. Most Linux kernels also work plug-and-play, but macOS is not supported. A full-height bracket is preinstalled, and a low-profile bracket is included for slim cases.

Product Info

The FS-HA-Pro is available through online retailers for around 5,410 yen. It ships with the card, a low-profile bracket, and driver support for older Windows systems. Warranty details are not clearly published, so check the listing before purchase. In the market, this card sits in the entry-to-mid tier: it uses a reputable Renesas controller and self-power technology, yet remains affordable and easy to install.

Best Use Cases

  • Desktop users who need more rear USB-A ports for peripherals like keyboards, mice, and external drives. - Builders who want front-panel USB 3.0 connectivity by connecting the 19-pin header to their case. - Users with slim or small-form-factor PCs, thanks to the included low-profile bracket. - Anyone running power-hungry USB devices such as external SSDs or capture devices, since each port can deliver up to 5V/2A.

Things to Consider

Make sure your motherboard has a free PCIe x1 (or larger) slot before buying. The card does not work in legacy PCI slots, and macOS users will need a different solution. To reach 5Gbps speeds, both the card and the connected device must support USB 3.0. Fast charging is not supported, so this is not a charging hub. ## FAQ
Q: Does this card need a power cable? A: No. The self-powered design draws power from the PCIe slot, so no additional power connection is required. Q: Will it work with Windows 7? A: Yes, but you need to install drivers. Windows 11, 10, and 8.x work plug-and-play. Q: Can I use it for front-panel USB ports? A: Yes. Connect the 19-pin header to your case's front-panel wiring to add two USB-A ports.
