This article covers ARCTIC P12 PWM BLACK 120mm角ファン ACFAN00119A.

Overview

The ARCTIC P12 PWM BLACK ACFAN00119A is a 120mm PWM fan from the German cooling specialist ARCTIC. It covers a wide speed range from 200 to 1800 RPM, delivering a maximum airflow of 56.3 CFM and a maximum static pressure of 2.20 mmH2O. Its static-pressure-optimized design makes it particularly effective for radiators and heatsinks where airflow resistance is high. Equipped with a Fluid Dynamic Bearing (FDB), this fan offers long-term durability and low noise operation. The maximum noise level is just 0.3 Sone, making it suitable for quiet builds. Priced in the entry-level range, it delivers an excellent balance of performance and silence.

Compatibility Guide

Standard 120×120×25mm dimensions fit most PC cases, CPU coolers, and radiators. Uses a 4-pin PWM connector for automatic speed control via the motherboard. Mounting screws are included; screw hole pitch is the standard 105mm. Cable length is 40cm, which is sufficient for most mid-tower cases but may require an extension for full-tower builds.

Product Info

The ARCTIC P12 PWM BLACK has been on the market since around 2020. It sits in the entry-to-mid-range segment, with a street price of roughly ¥1,000 per fan, offering outstanding value. The warranty period is 2 years, and it is widely available through major online retailers like . This fan belongs to ARCTIC's F-series, designed for static-pressure applications such as radiators and CPU coolers. The new motor design reduces vibration by about 5% compared to conventional DC motors, and lower coil temperatures extend motor life by approximately four times.

Best Use Cases

Silent PC builders: With a maximum noise of 0.3 Sone and the ability to drop to 200 RPM at idle, this fan is barely audible, making it ideal for overnight use or recording environments. AIO liquid cooling or air tower coolers: The 2.20 mmH2O static pressure provides enough force to push air through dense radiator fins or tall heatsink towers, maximizing cooling performance. * Budget-conscious users seeking reliability: At around ¥1,000 per unit, the FDB bearing and German-developed alloy/lubricant combination ensure long-term dependability without breaking the bank. ## Alternatives
Direct competitors in the same price tier include the Noctua NF-P12 redux-1200 PWM (around ¥1,500) and the be quiet! Pure Wings 2 120mm PWM (around ¥1,200). The Noctua redux offers a lower maximum static pressure of 1.68 mmH2O and a lower top speed of 1200 RPM. The be quiet! Pure Wings 2 runs at up to 1500 RPM with 1.25 mmH2O static pressure, again trailing the P12 in static pressure. The ARCTIC P12 PWM BLACK can spin up to 1800 RPM, giving it more headroom under heavy loads. However, noise increases near maximum speed, so PWM control is recommended for those prioritizing silence.

Things to Consider

Because this fan is static-pressure-optimized, its airflow is slightly lower than airflow-optimized models (such as ARCTIC's own airflow-focused variants). For case intake/exhaust, consider pairing it with an airflow-focused fan on the intake side. The stated maximum noise of 0.3 Sone may vary in real-world use due to case resonance and mounting conditions. The 2-year warranty is shorter than some high-end competitors (e.g., Noctua's 6-year warranty). Keeping a spare fan on hand is advisable for long-term builds. The 40cm cable may be too short for large tower cases or depending on motherboard fan header placement; a fan extension cable may be needed.

Product Disclosure (Amazon)

  • Manufacturer: ARCTIC
  • ASIN: B07GB5JRTZ
  • Note: This article covers a manufacturer-made product based on Amazon listing details.
